VTX 7200 CLASS H LIMITED EDITION

The VTX 7200 is the amplifier we build when there is no compromise to make. Class H, 2 ohm stable, and engineered for one job above all others: driving subwoofers hard, for hours, without the low end going soft.

Where our MT series is built for full-range work, the VTX 7200 hits harder at the bottom. A damping factor of 1000:1 means it grips the woofer cone and stops it on command — which is the difference between a kick you feel as a distinct hit and one that arrives as a boom smearing into the next note. An 80V/µs slew rate keeps transients sharp instead of rounded off.

The built-in low-pass filter means you can run subs directly without an external crossover in the chain, and the 0dB limiter protects your drivers when the night gets enthusiastic. This is a flagship amplifier at a price that does not read like one — because we sell it directly from our own factory.

• Class H Flagship
• Dual Channel
• 2 Ohm Stable
• UTC Original Transistors
• Built-in LPF
• 0dB Limiter
• Damping Factor 1000:1
• Bridge Mode

• 2800WPer channel @ 2 ohms
• 2100WPer channel @ 4 ohms
• 1700WPer channel @ 8 ohms
• Class HAmplifier topology

• 6500WBridged @ 4 ohms
• 4200WBridged @ 8 ohms
• 1000:1Damping factor
• 80V/µsSlew rate

All figures measured at 1 kHz, 0.1% THD.

• Damping factor of 1000:1 — the amplifier brakes the cone after each note instead of letting it wobble. Tight, defined bass rather than boom.
• 80V/µs slew rate — transients stay sharp. A kick drum arrives as a hit, not a swell.
• Built-in low-pass filter — run subs directly, no external crossover needed in the chain
• 0dB limiter built in — protects your drivers without you watching the meters all night
• Stable into 2 ohms — real current reserve for parallel sub loads
• Bridge mode up to 6500W at 4 ohms for single high-power drivers

• 10 complementary output pairs per channel, UTC originals — genuine devices with full die area
• 3 switching pairs per channel — Class H rail switching handled properly
• Eight 22,000µF / 80V filter capacitors — the reservoir that holds the low end together
• 106 dB signal to noise ratio — a quiet noise floor, so quiet passages stay quiet
• Three input sensitivity settings — 0.775V, 1.0V and 1.55V to match your desk
• Full indicator set — Signal, Protect, Clip and Limiting
• Pure copper transformer, wound in our own factory
• Tested at full load before dispatch — every unit, not a sample

The VTX 7200 is a flagship amplifier and it will show you exactly what it is being fed. Pair it with a good quality mixer. A noisy or poorly-gained source will be reproduced faithfully — a 106 dB signal-to-noise floor cuts both ways. If your current desk is the weak link, fix that first and this amplifier will reward you for it.

Subwoofer and bass duty · Line arrays · Large outdoor events · Touring rigs · Clubs with serious low end
